Persian Gulf Star Refinery, also known as Bandar Abbas Gas Condensate Refinery, is a new gas condensate refinery being developed near Bandar Abbas, Iran.
It will have a processing capacity of roughly 360,000 barrels of gas condensate a day upon becoming fully operational in 2018.
Recommended White Papers
Recommended Buyers Guides
The facility is owned by Oil, Gas and Petrochemical Investment Company (49%), Oil Industry Pension Fund (33.1%) and National Iranian Oil Refining and Distribution Company (NIORDC) (17.9%).
The project is estimated to be completed at a cost of approximately $3.4bn.
Phase one of the refinery was officially inaugurated in April 2017, while the first shipment of gasoline was delivered for distribution in June 2017. The remaining two phases are scheduled to be commissioned by March 2018.
The refinery will produce high-quality gasoline in order to make Iran self-sufficient in gasoline production.
It will also enable the nation to export gasoline and other high-value products to foreign countries.
Persian Gulf Star refinery project details
The gas condensate refinery will be the first of its kind in Iran and is located on 700ha of land on the western side of the existing refinery, approximately 25km away from Bandar Abbas.
Each of the three phases of development are designed to produce 12 million litres a day (Ml/d) of Euro-IV grade gasoline, 4.5Ml/d of Euro-IV diesel, 1Ml/d of kerosene and 300,000l of liquefied petroleum gas (LPG) a day.
The gas condensate to be refined is supplied from the South Pars offshore gas field, which is located in the territorial waters between Iran and Qatar in the Persian Gulf.
Persian Gulf Star Refinery make-up
The refinery will integrate three 120,000 barrels per day (bpd) distillation units, two 13,000bpd UOP LPG Merox units, two 15,000bpd LPG recovery units and three 78,000bpd Axens naphtha hydrotreaters.
Three 45,000bpd Axens continuous catalytic reformer (CCR) units and three UOP isomerisation units with a capacity of 30,000bpd each are also set to be installed at the facility.
The oil purification unit will include a 25,000bpd Topso Kerosene Hydrotreater (KHT), while the gas oil purification unit will integrate two 42,000bpd Topso Gas Oil Hydrotreaters (GOHTs).
Additionally, the refinery is to be equipped with two JTI sulphur recovery units, each with a capacity of 85t/d, as well as two purification units with sour water strippers and two gas purification units with amine treating units.
Contractors involved
The joint venture between Tehran Jonoob and Bina has been selected as the engineering, procurement and construction (EPC) contractor for the project.
RAJAN provided detailed engineering for the distillation, naphtha recovery and CCR units, distributed control system, pipe-rack area, and flare system.
Radira was contracted to provide EPC services for the 26 storage tanks at the Persian Gulf Star refinery, while Bajak Paint supplied paints for the storage tanks.
Ebdaagaran Padide (E.G.P.) was awarded a contract to supply more than 700,000m² of aluminium jacketing and insulation for the development.
Kanrood Sazeh constructed internal and patrol roads, the main refinery fence, foundations for tanks and equipment, and underground piping for the project.
Datam is responsible to provide pipe racks, and pipe supports structure and foundation design, as well as equipment foundation design.
Khatam al-Anbiya Construction Headquarters, controlled by the Islamic Revolution Guards Corps (IRGC), is one of the main contractors involved in the refinery’s construction.
Nardis was awarded an engineering, procurement, construction and commissioning (EPCC) contract for the facility’s process units, utility units and industrial buildings.
SADRA provided a seawater intake system for the site. Delta Offshore Technology was subcontracted by SADRA for the engineering and installation of pipelines.
ZAFARAN Industrial Group supplied a sulphur solidification unit for installation at the refinery, which includes a granulator drum, cyclone filter, sulphur buffer tank, conveyors, storage silos and switchgear.
